Bornier de racc. RKA 1p double 50mm² Cu+Al noir

I(max):
1000Vac/dc 150A Cu
600V 150A Cu/120A Al

additional measurement terminal integrated by default

IP20

halogen-free, self-extinguishing

captive screws with constant tightening torque

can be coupled with RKA 95mm² terminals

mounting on DIN rail or by screws

earth terminal color according to standard IEC60947-7-1

with profile for marking

for Cu and Al conductors
