Micro contacteur industriel 4kW 3~400V 24V 50/60Hz
Internal Reference: K005D0124
U(max) : 415 Vac
contact opening > 3mm to IEC 60335-1 for safety applications
dimensions: H x W x D: 33 x 35.5 x 32mm
DIN15 (EN60715) rail mounting - 35mm DIN rail adapter available
contact opening > 3mm to IEC 60335-1 for safety applications
dimensions: H x W x D: 33 x 35.5 x 32mm
DIN15 (EN60715) rail mounting - 35mm DIN rail adapter available
| P(n) AC3 400V: 2.2 kW |
| U(n) bobine: 24 Vac |
| I(n) AC1 400V: 12 A |
| I(n) AC3: 5 A |
| Integrated auxiliary contacts: 1 nf|1 ng |
