Cont. f. Capac. 50kVAr 3~400V 220-240V 50Hz 240V 60Hz
Internal Reference: K362K00230
U(max) : 690 Vac
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
designed to switch low-induction and low-loss capacitor banks with or without reactors
equipped with advanced contacts and resistors that limit peak current to < 70 x I(e)
in the table:
P(r) XX YYY = Nominal reactive power at XX °C in YYY V AC
ex: P(r) 50 400 = Rated reactive power at 50°C in 400V AC
| U(n) bobine: 230 Vac |
| Attachable auxiliary contacts: 2 HB... + 1 HN.../HA... |
| P(r)50 400kVAr: 20 |
| P(r)50 440kVAr: 23 |
| P(r)50 690kVAr: 36 |
| P(r)60 400kVAr: 20 |
| P(r)60 440kVAr: 23 |
| P(r)60 690kVAr: 36 |
